    Low Air Pressure Hepa Filter Paper Roll PP Meltblown Material

    Ask Lasest Price
    Brand Name : CHANGFENG
    Model Number : 9009-55-2
    Certification : ISO9001:2008
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 30 Ton/Tons per Quarter
    Delivery Time : 1 - 5000 Est. Time15(days)
    • Product Details
    • Company Profile

    Low Air Pressure Hepa Filter Paper Roll PP Meltblown Material

    Resistance high quality PTFE HEPA filter paper

    1. Product introduction


    This polyester filter media with/without PTFE membrane is made of high quality filament yarn without using any binding agent. It has been widely applied in making pleated dust collection cartridges. This hard finished material is very stable & structurally durable. This unique & hard finished material provides features of good pleatability, high durable, and unique structure of very fine filament yarn which offer high performance in filtration. This filter media with PTFE membrane provides excellent stable structure, fine dust release & good release & good resistance of particle penetration in to the media. This spun bonded polyester filter media are pleated in different pleated depths & height to accommodated desired filtration area.


    2. Parameter table


    PP Meltblown

    Part No.WeightThicknessEfficiencyResistance (Pa)European Efficiency ClassMax. WidthRoll Length (m)
    (g/m2)(mm)(%)(mm)
    SMR8520±20.21±0.03≥85≤7H101500±5500
    SMR9020±20.21±0.03≥90≤8H10
    SMR9520±20.21±0.03≥95≤10H11
    SMR9820±20.21±0.03≥98≤12H11
    SMR99520±20.21±0.03≥99.5≤16H12
    SMR999730±20.33±0.03≥99.97≤25H13
    SMR999940±20.43±0.03≥99.99≤30H14

    PP Melt-blown + PET Composited Filter Paper

    Part No.Weight(g/m²)Thickness(mm)Efficiency(%)Resistance (Pa)European Efficiency ClassMax. Width(mm)Roll Length (m)
    MG-P85%85±100.55±0.05≥85≤9H101470±5500
    MG-P90%85±100.55±0.05≥90≤10H10
    MG-P95%85±100.55±0.05≥95≤12H11
    MG-P98%85±100.55±0.05≥98≤14H11
    MG-P99.5%85±100.55±0.05≥99.5≤18H12
    MG-P99.97%95±100.65±0.05≥99.97≤27H13
    MG-P99.99%105±100.75±0.05≥99.99≤32H14

    3. Production process


    This polyester filter media with/without PTFE membrane is made of high quality filament yarn without using any binding agent. It has been widely applied in making pleated dust collection cartridges. This hard finished material is very stable & structurally durable. This unique & hard finished material provides features of good pleatability, high durable, and unique structure of very fine filament yarn which offer high performance in filtration.


    4. Packing details


    Vacuum Cleaner Cooking Oil The Truck Air Filter Paper 1,Inner Packing:Plastic Film 2,Middle Packing:Craft Paper 3,Outer Packing:Plastic Film 4,top and bottom Packing:Paper pallet 5,20ft can load 5.5-6 tons 6,40HQ can load 13.5-16 tons (110 g Hepa Roll Filt
