    380v Car Air Filter Making Machine , Pp Melt Blown Non Woven Fabric Making Machine

    Ask Lasest Price
    Brand Name : Chang Feng
    Model Number : 9009-54-88
    Certification : CE,ISO
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 200 Set/Sets per Year
    Delivery Time : 8-10 work days
    • Product Details
    • Company Profile

    380v Car Air Filter Making Machine , Pp Melt Blown Non Woven Fabric Making Machine

    380v Filter Paper , Wire Mesh, Non Woven Fabric Computerized High Efficiently Air Filter Making Machine

    1. Product introduction

    This machine can pleating : filter paper,wiresh, window screen, cardboard , synthetic , copper , aluminum , Metallic Foils and so on.


    2. Parameter table


    Pleating height

    8 - 55mm

    Layers pleated

    1 - 5

    Pleating speed

    20 - 150 pleats/min

    Max. pleating width

    1100mm

    Thickness of material

    0.5 - 4mm

    Speed adjustable motor

    1.5KW

    Power

    1.5KW 380V Heater Power: 3KW Heat Temperature: 200°C

    Machine weight

    800kgs

    Machine dimension

    1430mm x 1550mm x 1400mm

    Alternative width

    B-600,B-800,B-1500,B-2100,B3000 mm

    Alternative height

    15-160 mm


    3. Product characteristics


    The folding machine adopts the alternate method of upper and lower knives to complete the folding work. The knife distance is automatically adjusted by the computer, which can meet the requirements of various folding heights, and the size is accurate and flat.

    4. Product advantage


    1. The filter material is glued and folded on the same machine. After the filter paper is formed, it is transported by a longer conveyor belt so that the hot melt adhesive can be cured and cut to the required length.
    2. Both the host and the conveyor are controlled by the frequency converter, which is easy to adjust.
    3. The travel distance of the filter material after gluing can be adjusted within a certain range, which is conducive to the dry humidity of the hot melt adhesive, so that it can be folded firmly.
    4. Six sets of rollers are on the same disk, which is easy to replace and adapt to the production of different specifications.
    5. The glue melting speed is fast, and the amount of glue can be adjusted through the frequency converter.
    6. This machine has high production efficiency and good product flatness.
    The company can also customize origami production lines of different specifications according to your needs.
