Brand Name : | ChangFeng |
Model Number : | 9009-54-84 |
Certification : | ISO9001 |
Price : | Negotiable |
Payment Terms : | L/C, T/T |
Supply Ability : | 5000 Set/Sets per Week filter end caps 5000 sets/week |
Delivery Time : | 8-10 work days |
MOQ : | 50 PCS |
The filter end cap is mainly used to seal both ends of the filter material and support the filter material to effectively improve the bearing capacity of the filter material. Chang Feng has been specialized in metal filter end caps since 1996 with a wide range of existing molds for air filter end caps for the cartridge filter. We are able to advise customers on the best material proper thickness opt for. Welcome to contact us to have further discussion.
There are parts of specifications of filter caps we made for clients before for your reference. If you need other shapes, we could make customization.
Open Round End Cap with Tri-Bolt Holes | |||
Inches | Millimeters | ||
Outer diameter | 12.75 | 323.85 | |
Inner diameter | 8.5 | 215.9 | |
Inner height | 0.54 | 13.716 | |
Outer height | 0.5 | 12.7 | |
Inner rim diameter | 6.75 | 171.45 | |
Open Round End Cap with Outer Lip | |||
Inches | Millimeters | ||
Outer diameter | 12.75 | 323.85 | |
Inner diameter | 8.5 | 215.9 | |
Inner diameter | 0.625 | 15.875 | |
Outer height | 0.368 | 9.3472 | |
Lip | 0.375 | 9.525 | |
Open Round End Cap | |||
Inches | Millimeters | ||
Outer diameter | 12.75 | 323.85 | |
Inner diameter | 8.5 | 215.9 | |
Inner height | 0.5 | 12.7 | |
Outer Height | 0.5 | 12.7 | |
Closed Round End Cap | |||
Inches | Millimeters | ||
Outer diameter | 12.75 | 323.85 | |
Inner diameter | 8.375 | 212.725 | |
Inner height | 0.5 | 12.7 | |
outer height | 0.5 | 12.7 | |
Closed Round End Cap with Bolt Hole | |||
Inches | Millimeters | ||
Outer diameter | 12.75 | 323.85 | |
Inner diameter | 8.375 | 212.725 | |
Inner height | 0.5 | 12.7 | |
Outer height | 0.5 | 12.7 | |
Bolt Hole | 0.625 | 15.875 | |
Open Round End Cap with Flange | |||
Inches | Millimeters | ||
Outer diameter | 5.75 | 146.05 | |
Inner diameter | 2.5 | 63.5 | |
Inner height | 0.5 | 12.7 | |
Outer height | 0.278 | 7.0612 | |
Closed Round End Cap | |||
Inches | Millimeters | ||
Outer diameter | 5.25 | 133.35 | |
Inner diameter | 2.5 | 63.5 | |
Inner height | 0.875 | 22.225 | |
Outer height | 0.172 | 4.3688 |
3. Product advantage
25 years' experience in producing filter end caps.
2. Accurate size according to customer requirements
3. Ensure the filters have a longer life with excellent heat and
chemical resistance.
4. Effectively improve the capacity of the filter material.
5. Various exist mold to save your cost.
6. Qualified raw materials with certifications to make the filter
caps.
we can provide a free sample with our catalog. But the courier charge will on your side. We'll send back the courier charge if you make an order.
5. Technology
Ensure the filters have a longer life with excellent heat and
chemical resistance.
Effectively improve the capacity of the filter material.
Various exist mold to save your cost.
Metal raw materials use stamping technology to achieve the desired shape and effect of the product.
![]() |
