    232 Degree O Ring Style Air Filter Material For Sealing Industry

    Ask Lasest Price
    Brand Name : Chang Feng
    Model Number : Rubber ring
    Certification : ISO9001
    Price : Negotiable
    Supply Ability : 25 Roll/Rolls per Week
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    232 Degree O Ring Style Air Filter Material For Sealing Industry

    Manufacturer Air Filter Media Rubber Sealing Ring Car Parts


    1. Prodcut introduction

    It is used to install on various mechanical equipment, in the specified temperature and pressure, as well as different liquids and gases, to play a sealing role in the static or moving state.


    2. Data Sheet


    Rubber material
    Letter abbreviation
    hardness
    temperature
    Attributes
    Nitrile rubberNBR
    standard 70°
    customizable 40°~90°
    Limit temperature
    -40°~120℃
    Oil resistant wear resistant
    VitonFKM/VITON
    standard 75°
    customizable 50°~90°
    Limit temperature
    -40°~240℃
    High temperature resistant
    Oil resistant
    Chemical resistance
    Silica gel
    SIL/VMQ
    standard 70°OR60°
    customizable 40°~90°
    Limit temperature
    -60°~250℃
    High temperature resistant
    Low temperature resistant
    Avirulent insipidity
    Food grade
    EPDMEPDM
    standard 70°
    customizable 40°~90°
    Limit temperature
    -40°~150℃
    Strong acid and alkali resistance
    Resistant to 150° steam
    anti-aging
    Resistance to ozone
    Hydrogenated nitrile
    HNBR
    standard 70°
    customizable 40°~90°
    Limit temperature
    -40°~150℃
    Wear oil resistantResistance to cold media
    Polar-resistant solvent
    The deformation resistance
    Chlorosilicone rubberCR
    standard 70°
    customizable 40°~90°
    Limit temperature
    -40°~120℃
    Ozone resistant
    Weather resistance
    Chemical resistance
    Anti-aging
    Fluorosilicone rubber
    FVMQ
    standard 70°
    customizable 45°~70°
    Limit temperature
    -60°~177℃
    Oil resistance, acid and alkali resistance
    Heat resistance, cold resistance, high voltage resistance, atmospheric aging resistance, hydrocarbon solvent resistance
    Perfluoroether rubberFFKM
    standard 75°
    customizable 50°~90°
    conventional
    250℃
    Special formula
    320°~330℃
    Very excellent performance, can almost be used in all kinds of bad conditions, PTFE as excellent high temperature resistance,
    chemical resistance, corrosion resistance, can resist all kinds of solvents, while having the elasticity of rubber
    PTFEPTFE/F4Generally 55°~65°
    Generally
    -80°~260℃
    Reachable
    -190°~260℃
    Corrosion resistance, wear resistance, high temperature resistance, low temperature resistance, aging resistance, high pressure
    resistance, organic solvents (almost insoluble in all organic solvents)

    3. Product advantages


    1. The sealing ring shall have good sealing performance within the working pressure and certain temperature range, and can automatically improve the sealing performance with the increase of pressure.

    2. The friction between the sealing ring device and the moving parts shall be small and the friction coefficient shall be stable.

    3.The rubber O-ring has excellent sealing performance and high service life. The service life of dynamic pressure seal is 5-10 times higher than that of conventional rubber seal products, up to dozens of times. Under some conditions, it can have the same service life as the sealing matrix.

    4. Why choose us ?


    1. Quick response in 12 hours


    2.Reliable imported raw material


    3.Strict analysis and testings on raw material before production


    4. Assistance from first idea through prototype


    5.First prototype inspection after mould and before volume production

    6.Quick delivery of prototypes or production needs

    7.Design assistance and parts consolidation

    8.In-house mold design (Insert, polyurethane, urethane molding)

    9.In-house formulations to provide the best possible urethane for your application

    10. Low-cost tooling


    11.Over 20 years of in-house experience


    12.Reliable after-sales service and support


    5. Installation method


    1. Put the sponge cover on the split ends, and evenly apply about 0.5mm of grease on the inner circumference.

    2. After removing the sponge sheath, apply a special adhesive to the section mold under the split.

    3.The butt split surface is pressed tightly and held for 10 to 20 seconds.
